Optical Transceiver 1.25Gbps Single 100m SFP

AMP, LOW NOISE, HI GAIN, 6UDFN; Frequency Min:900MHz; Frequency Max:3.5GHz; Gain:19.6dB; Noise Figure Typ:1dB; RF IC Case Style:uDFN; No. of Pins:6Pins; Supply Voltage Min:-; Supply Voltage Max:3.3V; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; MSL:-; SVHC:No SVHC (12-Jan-2017); Frequency Range:900MHz to 3.5GHz; Operating Temperature Range:-40°C to +85°C; Power Dissipation Pd:60mW; RF Type:GPS, ISM, WiMAX; Supply Current:6mA

AMP, POWER, UMTS, BAND 5, 4X4 SMD; Frequency Min:824MHz; Frequency Max:849MHz; Gain:27dB; Noise Figure Typ:-; RF IC Case Style:SMD; No. of Pins:10Pins; Supply Voltage Min:3.2V; Supply Voltage Max:4.2V; Operating Temperature Min:-20°C; Operating Temperature Max:85°C; MSL:MSL 3 - 168 hours; SVHC:No SVHC (12-Jan-2017); Frequency Range:824MHz to 849MHz; Operating Temperature Range:-20°C to +85°C; RF Type:UMTS; Supply Current:485mA; Supply Voltage Range:3.2V to 4.2V

AMP, POWER, UMTS, BAND 1, 4X4 SMD; Gain:27dB; Noise Figure Typ:-; RF IC Case Style:SMD; No. of Pins:10Pins; Supply Voltage Min:3.2V; Supply Voltage Max:4.2V; Operating Temperature Min:-20°C; Operating Temperature Max:85°C; MSL:MSL 3 - 168 hours; SVHC:No SVHC (12-Jan-2017); Operating Temperature Range:-20°C to +85°C; RF Type:UMTS; Supply Current:480mA; Supply Voltage Range:3.2V to 4.2V

AMP, POWER, CDMA/AMPS, 4X4 SMD; Frequency Min:824MHz; Frequency Max:849MHz; Gain:28dB; Noise Figure Typ:4.5dB; RF IC Case Style:SMD; No. of Pins:10Pins; Supply Voltage Min:3.2V; Supply Voltage Max:4.2V; Operating Temperature Min:-30°C; Operating Temperature Max:85°C; MSL:MSL 3 - 168 hours; SVHC:No SVHC (12-Jan-2017); Frequency Range:824MHz to 849MHz; Operating Temperature Range:-30°C to +85°C; Power Dissipation Pd:2.5W; RF Type:CDMA; Supply Current:520mA; Supply Voltage Range:3.2V to 4.2V

LED, 3W, NEUTRAL WHITE 3800K, 180LM; LED Colour:Neutral White; LED Mounting:SMD; Bulb Size:-; Forward Current If:-; Forward Voltage:-; Luminous Intensity:-; Viewing Angle:140°; Lens Shape:-; Product Range:-; MSL:-; SVHC:No SVHC (12-Jan-2017); CCT:3800K; Forward Current @ Test:350mA; Forward Current If Max:700mA; Forward Voltage @ Test:3.2V; Luminous Flux @ Test:105lm; No. of Pins:6Pins; Operating Temperature Max:135°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +135°C; Power @ Test:1.1W; Power Dissipation Pd:3W

LED, SMD, ORANGE; LED Colour:Orange; LED Mounting:SMD; LED Case Size:1.25mm x 1.4mm; Forward Current If:20mA; Forward Voltage:1.9V; Wavelength Typ:605nm; Luminous Intensity:90mcd; Viewing Angle:170°; Lens Shape:Rectangular; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 2A - 4 weeks; SVHC:No SVHC (15-Jan-2018); Bulb Size:1.25mm x 1.4mm; Dominant Wavelength:604nm; External Depth:0.8mm; External Length / Height:2mm; External Width:1.25mm; Forward Current If Max:20mA; Forward Voltage VF Max:2.4V; LED Type:Standard; Light Output Orientation:Top Emitting; Luminous Intensity @ If Min:28.5mcd; Luminous Intensity Typ:90mcd; Material:AllnGaP; No. of Pins:2Pins; Operating Temperature Max:85°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +85°C; Opto Mounting Orientation:Top; PIV Max:5V; Peak Wavelength:609nm; Reverse Protection Voltage:5V; Storage Temperature Max:85°C; Storage Temperature Min:-40°C; Voltage Vf Min:1.9V; Voltage Vf Typ:1.9V

LED, SMD, YELLOW; LED Colour:Yellow; LED Mounting:SMD; LED Case Size:0.8mm x 1mm; Forward Current If:20mA; Forward Voltage:2.1V; Wavelength Typ:572nm; Luminous Intensity:8mcd; Viewing Angle:170°; Lens Shape:Rectangular; Product Range:-; Automotive Qualification Standard:-; MSL:MSL 2A - 4 weeks; SVHC:No SVHC (15-Jan-2018); Bulb Size:0.8mm x 1mm; Dominant Wavelength:586nm; External Depth:0.6mm; External Length / Height:1.6mm; External Width:0.8mm; Forward Current If Max:20mA; Forward Voltage VF Max:2.6V; LED Type:Standard; Light Output Orientation:Top Emitting; Luminous Intensity @ If Min:2.8mcd; Luminous Intensity Typ:8mcd; Material:GaP; No. of Pins:2Pins; Operating Temperature Max:85°C; Operating Temperature Min:-30°C; Operating Temperature Range:-30°C to +85°C; Opto Mounting Orientation:Top; PIV Max:5V; Peak Wavelength:570nm; Reverse Protection Voltage:5V; Storage Temperature Max:85°C; Storage Temperature Min:-40°C; Voltage Vf Min:2.1V; Voltage Vf Typ:2.1V

LED, 5MM, 30DEG, RED; LED Colour:Red; LED Mounting:Through Hole; Forward Current If:20mA; Forward Voltage:2.4V; Wavelength Typ:639nm; Luminous Intensity:5.5cd; Viewing Angle:30°; Lens Shape:Round; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Current If(AV):30mA; Forward Voltage VF Max:2.5V; Head Diameter:5.8mm; LED / Lamp Size:5mm / T1.3/4; Lead Length:22.89mm; Lens Colour:Untinted, Non-diffused; Lens/Filter Width:5mm; Luminous Intensity @ If Min:1900mcd; Luminous Intensity Typ:5500mcd; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; Peak Forward Current:100mA; Peak Wavelength:639nm; Reverse Protection Voltage:20V; Voltage Vf Typ:1.9V

LED, 5MM, 15DEG, BLUE; LED Colour:Blue; LED Mounting:Through Hole; Forward Current If:20mA; Forward Voltage:3.2V; Wavelength Typ:525nm; Luminous Intensity:7.2cd; Viewing Angle:15°; Lens Shape:Round; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Current If(AV):30mA; Forward Voltage VF Max:4V; Head Diameter:5.8mm; LED / Lamp Size:5mm / T-1 3/4; Lead Length:19.64mm; Lens/Filter Width:5mm; Luminous Intensity @ If Min:2500mcd; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +85°C; Peak Forward Current:100mA; Peak Wavelength:516nm; Reverse Protection Voltage:5V; Voltage Vf Typ:3.6V

IC, MMIC AMPLIFIER, SOIC4, 886; No. of Pins:4Pins; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; MSL:-; SVHC:No SVHC (12-Jan-2017); Bandwidth:5.5GHz; Base Number:0886; Device Marking:MSA-0886; IC Generic Number:0886; Logic Function Number:0886; Operating Temperature Range:-40°C to +85°C; Termination Type:Surface Mount Device

LED, SMD ALGAAS RED; LED Colour:Red; LED Mounting:SMD; LED Case Size:1.25mm x 1.4mm; Forward Current If:20mA; Forward Voltage:1.8V; Wavelength Typ:639nm; Luminous Intensity:16mcd; Viewing Angle:155°; Lens Shape:Rectangular; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:1.25mm x 1.4mm; Current If Luminous Intensity:20mA; External Depth:1.1mm; External Length / Height:2mm; External Width:1.25mm; Forward Current If Max:20mA; Luminous Intensity Typ:16mcd; Mounting Orientation:Vertical; Opto Mounting Orientation:Vertical; PIV Max:5V; Peak Forward Current:20mA; Peak Wavelength:650nm; Tape Width:8mm

LED, SMD, PLCC4, RGB; LED Colour:Red, Green, Blue; LED Mounting:SMD; Bulb Size:-; Viewing Angle:120°; Lens Shape:Round; Forward Current / Colour:R 30mA, G 30mA, B 20mA; Luminous Intensity / Colour:R 80mcd, G 160mcd, B 10mcd; Forward Voltage / Colour:R 1.9V, G 3.4V, B 3.9V; Wavelength / Colour:-; MSL:-; SVHC:No SVHC (12-Jan-2017); Operating Temperature Max:100°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +100°C

LED, 5MM, 55DEG, RED; LED Colour:Red; LED Mounting:Through Hole; LED Case Size:T-1 3/4 (5mm); Forward Current If:20mA; Forward Voltage:2V; Wavelength Typ:630nm; Luminous Intensity:1.15cd; Viewing Angle:55°; Lens Shape:Round; Product Range:-; Automotive Qualification Standard:-; MSL:-; SVHC:No SVHC (15-Jan-2018); Bulb Size:T-1 3/4 (5mm); Current If Luminous Intensity:20mA; Dominant Wavelength:630nm; External Diameter:5mm; External Length / Height:8.71mm; Forward Current If Max:20mA; Forward Voltage VF Max:2V; LED / Lamp Size:5mm / T-1 3/4; LED Type:Standard; Lead Cross-section Width:0.5mm; Lead Length:23mm; Lead Spacing:2.54mm; Lens Diameter:5mm; Luminous Intensity Max:1150mcd; Luminous Intensity Min:400mcd; Luminous Intensity Typ:345mcd; No. of Pins:2Pins; Operating Temperature Max:100°C; Operating Temperature Min:-40°C; Operating Temperature Range:-40°C to +100°C; PIV Max:5V; Peak Forward Current:50mA; Peak Wavelength:639nm; Voltage Vf Typ:2V

Isolation Amplifier 1 Circuit Differential 8-DIP

RF Diode PIN - 2 Independent 50V 1A MiniPak 1412

DIODE, PIN, SOD-323; Diode Configuration:-; Resistance @ If:1.5ohm; Breakdown Voltage Vbr:-; Diode Case Style:SOD-323; No. of Pins:-; Total Capacitance Ct:-; Forward Current If(AV):1A; Operating Temperature Max:-; Product Range:HSMP Series; Automotive Qualification Standard:-; MSL:MSL 1 - Unlimited; SVHC:No SVHC (12-Jan-2017); Capacitance Cd Max @ Vr F:0.2pF; Capacitance Ct:0.2pF; Diode Type:RF; Junction Temperature Tj Max:150°C; Pin Configuration:Band denotes Cathode; Repetitive Reverse Voltage Vrrm Max:100V; Termination Type:Surface Mount Device

OPTOCOUPLER, TRANSISTOR O/P; No. of Channels:1 Channel; Optocoupler Case Style:DIP; No. of Pins:8Pins; Forward Current If Max:25mA; Isolation Voltage:5kV; CTR Min:19%; Collector Emitter Voltage V(br)ceo:20V; Product Range:-; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA, DIN, EN, IEC; Approval Category:UL Recognised; CMR:30kV/µs; Current Transfer Ratio Min:15%; Current Transfer Ratio Typ:25%; External Depth:9mm; External Length / Height:5.1mm; External Width:11.15mm; Fall Time tf:0.2µs; Forward Current If(AV):16mA; Input Current:16mA; Lead Spacing:2.54mm; No. of Channels:1Channels; Operating Temperature Max:70°C; Operating Temperature Min:0°C; Operating Temperature Range:0°C to +70°C; Optocoupler Output Type:Phototransistor; Output Voltage:20V; Output Voltage Max:15V; Rise Time:0.6µs; Row Pitch:11mm; Voltage Vcc:15V; Withstand Voltage:5000VAC

DIODE, RF, PIN; Resistance @ If:1.5ohm; Diode Case Style:DO-15; No. of Pins:2 Pin; Forward Current If(AV):100mA; Product Range:5082 Series; MSL:-; SVHC:No SVHC (12-Jan-2017); Alternate Case Style:DO-204AC; Breakdown Voltage:200V; Capacitance Cd Max @ Vr F:0.3pF; Capacitance Ct:0.3pF; Device Marking:3077; Diode Series Resistance Rs:1.5ohm; Diode Type:RF; No. of Pins:2Pins; Peak Forward Current:100mA; Repetitive Reverse Voltage Vrrm Max:200V; Reverse Recovery Time trr Max:100ns; Termination Type:Axial Leaded; Vr Cd Measurement Voltage Max:50V

DIODE, RF, PIN; Diode Case Style:DO-15; No. of Pins:2 Pin; Product Range:5082 Series; MSL:-; SVHC:No SVHC (12-Jan-2017); Alternate Case Style:DO-204AC; Breakdown Voltage:100V; Capacitance Ct:0.4pF; Device Marking:3080; Diode Series Resistance Rs:2.5ohm; Diode Type:RF; High Resistance Limit Min:1000ohm; Low Resistance Limit Max:8ohm; No. of Pins:2Pins; Termination Type:Axial Leaded; Vr Cd Measurement Voltage Typ:50V
