95*191 GP FHT

FHT QDD 18W HEAT SINK

100*100*26 RJ

AAVID DESIGN PROPOSAL

HEAT SINK BGA 23 X 23 X 10 WITH PAD; Thermal Resistance: 40°C/W; Packages Cooled: BGA; External Width - Metric: 23mm; External Height - Metric: 10mm; External Length - Metric: 23mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 0.91"; External Height - Imperial: 0.39"; External Length - Imperial: 0.91"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (15-Jan-2019)

HEAT SINK BGA 27 X 27 X 18 WITH PAD; Thermal Resistance: 20.3°C/W; Packages Cooled: BGA; External Width - Metric: 27mm; External Height - Metric: 18mm; External Length - Metric: 27mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 1.06"; External Height - Imperial: 0.71"; External Length - Imperial: 1.06"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (15-Jan-2019)

HEAT SINK MAX CLIP - VERTICAL 100MM; Thermal Resistance: 3.19°C/W; External Width - Metric: 31mm; External Height - Metric: 39.8mm; External Length - Metric: 100mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 1.22"; External Height - Imperial: 1.57"; External Length - Imperial: 3.94"; External Diameter - Imperial: -; SVHC: No SVHC (15-Jan-2018)

HEAT SINK MAX CLIP - VERTICAL 50MM; Thermal Resistance: 5.17°C/W; Packages Cooled: -; External Width - Metric: 31mm; External Height - Metric: 39.8mm; External Length - Metric: 50mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 1.22"; External Height - Imperial: 1.57"; External Length - Imperial: 1.97"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (15-Jan-2018)

HEAT SINK MAX CLIP - STANDARD 50MM; Thermal Resistance: 4.45°C/W; Packages Cooled: TO-218, TO-220, TO-251, TO-262, TO-273; External Width - Metric: 40mm; External Height - Metric: 40mm; External Length - Metric: 50mm; External Diameter - Metric: -; External Width - Imperial: 1.57"; External Height - Imperial: 1.57"; External Length - Imperial: 1.97"; External Diameter - Imperial: -; SVHC: No SVHC (15-Jan-2018)

HEAT SINK MAX CLIP - STANDARD 100MM; Thermal Resistance: 3.03°C/W; Packages Cooled: TO-218, TO-220, TO-251, TO-262, TO-273; External Width - Metric: 30mm; External Height - Metric: 45mm; External Length - Metric: 100mm; External Diameter - Metric: -; Heat Sink Material: -; External Width - Imperial: 1.18"; External Height - Imperial: 1.77"; External Length - Imperial: 3.94"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (15-Jan-2019)

HEAT SINK MAX CLIP - STANDARD 100MM; Thermal Resistance: 2.22°C/W; Packages Cooled: TO-218, TO-220, TO-251, TO-262, TO-273; External Width - Metric: 38mm; External Height - Metric: 54mm; External Length - Metric: 100mm; External Diameter - Metric: -; Heat Sink Material: -; External Width - Imperial: 1.5"; External Height - Imperial: 2.13"; External Length - Imperial: 3.94"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (15-Jan-2019)

HEAT SINK MAX CLIP - STANDARD 100MM; Thermal Resistance: 3.24°C/W; Packages Cooled: TO-218, TO-220, TO-251, TO-262, TO-273; External Width - Metric: 30mm; External Height - Metric: 60mm; Available until stocks are exhausted

HEAT SINK, TO-3, 7.3°C/W; Thermal Resistance: 7.3°C/W; Packages Cooled: TO-3; External Width - Metric: 40.8mm; External Height - Metric: 25mm; External Length - Metric: 26.9mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 1.61"; External Height - Imperial: 0.98"; External Length - Imperial: 1.06"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (15-Jan-2019); Fixing Centres: 30.15mm; Fixing Hole Diameter: 4.1mm; Surface Finish: Black Anodised

HEAT SINK, TO-220, 7.1°C/W; Thermal Resistance: 7.1°C/W; Packages Cooled: TO-220; External Width - Metric: 42mm; External Height - Metric: 25mm; External Length - Metric: 38mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 1.65"; External Height - Imperial: 0.98"; External Length - Imperial: 1.5"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (17-Dec-2015); Fixing Hole Diameter: 4mm; Slot Length: 8.9mm; Slot Width: 3.8mm; Surface Finish: Black Anodised

HEAT SINK, T SLOTS, 0.41°C/W; Thermal Resistance: 0.41°C/W; Packages Cooled: -; External Width - Metric: 125mm; External Height - Metric: 135mm; External Length - Metric: 120mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 4.92"; External Height - Imperial: 5.31"; External Length - Imperial: 4.72"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (17-Dec-2015); Slot Pitch: 80mm; Surface Finish: Black Anodised

HEAT SINK; Packages Cooled: TO-92; Thermal Resistance: 60 C/W; External Height - Metric: -; External Width - Metric: 15.29mm; External Length - Metric: 18.29mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; Product Range: -

HEAT SINK; Thermal Resistance: 8°C/W; Packages Cooled: TO-3; External Width - Metric: 45.97mm; External Height - Metric: 12.7mm; External Length - Metric: 45.97mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; Height: 12.7mm

HEAT SINK EXTRUSION, 0.47°C/W, LED; Ther; HEAT SINK EXTRUSION, 0.47°C/W, LED; Thermal Resistance: 0.47°C/W; Packages Cooled: LED; External Width - Metric: 176.78mm; External Height - Metric: 70.87mm; External Length - Metric: 177.8mm; External Diameter - Metric: -; Product Range: -

HEAT SINK, TO-220/218, 6.8°C/W; Thermal Resistance: 6.8°C/W; Packages Cooled: TO-218, TO-220, TO-247; External Width - Metric: 34.5mm; External Height - Metric: 63mm; External Length - Metric: 12.5mm; External Diameter - Metric: -; Heat Sink Material: Aluminium; External Width - Imperial: 1.36"; External Height - Imperial: 2.48"; External Length - Imperial: 0.49"; External Diameter - Imperial: -; Product Range: -; SVHC: No SVHC (27-Jun-2018); Fixing Centres: 25.4mm; Fixing Hole Diameter: 2.6mm; Surface Finish: Black Anodised
