Switch Bezels / Switch Caps Toggle Switch Security Cap

Input Devices HF SERIES

Keylock Switches SP 45 DEG. MOM. KEY PULL POS 1

Switch Fixings SWITCH HARDWARE

Knobs & Dials KNRL PNTR 1/4" shft Line Indicator

SWITCH KEY SQUARE; For Use With:A01; IP / NEMA Rating:IP65; Product Range:-; SVHC:No SVHC (12-Jan-2017); Colour:Black; Contact Current @ Contact Voltage AC Max:6A; Contact Resistance:10mohm; External Depth:42mm; External Length / ;RoHS Compliant: Yes

SWITCH MOM GREEN; Contact Configuration:DPST-CO; Switch Operation:Off-(On); Switch Terminals:Quick Connect Solder; Contact Current Max:6A; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:12V; Pushbutton Actuator Style:-; IP ;RoHS Compliant: Yes

CONTACT BLOCK 2NO; Switch Terminals:Screw; No. of Poles:2 Pole; Contact Current Max:16A; Contact Voltage AC Max:-; For Use With:A02 Series Illuminated or Non-illuminated Pushbutton Switches; Contact Voltage DC Max:-; Product Range:-; SVHC:No SVHC (12-Jan-2017); Contact Configuration:2NO; Contact Current @ Contact Voltage AC Max:16A; Contact Current @ Contact Voltage AC Min:25mA; Contact Current Rating:16A; Contact Resistance:10mohm; Current Rating:16A; Insulation Resistance:50Mohm; Operating Temperature Max:85°C; Operating Temperature Min:-20°C

Rocker Switch DPST Off-On Red Panel 12 A 250 V ;RoHS Compliant: Yes

Rocker Switch DPST On-Off Black Panel 12 A 125 V ;RoHS Compliant: Yes

Rocker Switch DPST Off-On Red Panel 12 A 125 V ;RoHS Compliant: Yes

SWITCH DPDT LATCHING BLACK; Product Range:N Series; Contact Configuration:DPDT; Switch Operation:Off-On; Switch Terminals:Solder; Contact Current Max:2A; Contact Voltage AC Nom:250V; Contact Voltage DC Nom:-; Pushbutton Actuator Style:-; IP Rating:-; SVHC:No SVHC (12-Jan-2017); Actuator / Cap Colour:Black; Actuator Diameter:24mm; Actuator Type:Mushroom Head; Colour:Black; Contact Current @ Contact Voltage AC Max:2A; Contact Current AC Max:2A; Contact Resistance:10mohm; Contact Voltage AC Max:250V; External Depth:35.5mm; External Diameter:24mm; External Length / Height:55.2mm; External Width:35.5mm; No. of Electrical Operations:10000; Operating Temperature Max:70°C; Operating Temperature Min:20°C; Panel Thickness Max:8mm

SWITCH BCD COMPLEMENT; Product Range:PT65 Series; Switch Mounting:Through Hole; No. of Switch Positions:10 Position; Switching Voltage:24VDC; Output Code:BCD Complement; Switching Current:400mA; Switch Construction:Sealed; Actuator ;RoHS Compliant: Yes

SWITCH DECIMAL 4 POS; Product Range:PT65 Series; Switch Mounting:Through Hole; No. of Switch Positions:4 Position; Switching Voltage:24VDC; Output Code:Decimal; Switching Current:400mA; Switch Construction:Sealed; Actuator Level:Flushed; SVHC:No SVHC (12-Jan-2017); Contact Resistance:80mohm; Contact Voltage DC Max:24V; External Depth:10mm; External Length / Height:6.5mm; External Width:10mm; Flammability Rating:UL94V-0; Lead Spacing:2.54mm; No. of Mechanical Operations:10000; Operating Temperature Max:70°C; Operating Temperature Min:-20°C; Switching Current DC Max:150mA

SWITCH PCB SPDT CTR OFF; Contact Configuration:SPDT; Illumination:Non Illuminated; Switch Operation:On-Off-On; Product Range:TL Series; Switch Mounting:Through Hole; Contact Current Max:-; Contact Voltage AC Nom:20V; Switch Terminals:Solder; Contact Voltage DC Nom:20V; SVHC:No SVHC (12-Jan-2017); Actuation Type:Short Lever; Bush Length:6.1mm; Contact Current @ Contact Voltage AC Max:20mA; Contact Current @ Contact Voltage DC Max:20mA; Contact Resistance:10mohm; Contact Voltage AC Max:20V; Contact Voltage DC Max:20V; Dielectric Strength VDC:1000V; External Depth:5mm; External Length / Height:19.6mm; External Width:8.1mm; Height:19.6mm; Insulation Resistance:1000Mohm; No. of Electrical Operations:30000; Operating Force:2.16N; Operating Temperature Max:85°C; Operating Temperature Min:-30°C; Switching Power Max:0.4VA; Tab Blade Thickness:0.7mm

SWITCH PCB DPDT; Contact Configuration:DPDT; Illumination:Non Illuminated; Switch Operation:On-On; Product Range:TL Series; Switch Mounting:Through Hole; Contact Current Max:-; Contact Voltage AC Nom:20V; Switch Terminals:Solder; Contact Voltage DC Nom:20V; SVHC:No SVHC (12-Jan-2017); Actuation Type:Short Lever; Bush Length:6.1mm; Contact Current @ Contact Voltage AC Max:20mA; Contact Current @ Contact Voltage DC Max:20mA; Contact Resistance:10mohm; Contact Voltage AC Max:20V; Contact Voltage DC Max:20V; Dielectric Strength VDC:1000V; External Depth:24.9mm; External Length / Height:8.1mm; External Width:9.1mm; Height:8.1mm; Insulation Resistance:1000Mohm; No. of Electrical Operations:60000; Operating Force:2.16N; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Switching Power Max:0.4VA; Tab Blade Thickness:0.7mm

Toggle Switch TL Series DPDT On-Off-On Through Hole 20 V ;RoHS Compliant: Yes

SWITCH SPDT; Switch Operation:On-(On); Contact Configuration:SPDT; Contact Voltage AC Nom:20V; Contact Voltage DC Nom:20V; Contact Current Max:-; Switch Terminals:Solder; Product Range:TP Series; SVHC:No SVHC (12-Jan-2017); ;RoHS Compliant: Yes

SWITCH DPDT; Switch Operation:On-(On); Contact Configuration:DPDT; Contact Voltage AC Nom:20V; Contact Voltage DC Nom:20V; Contact Current Max:-; Switch Terminals:Solder; Product Range:TP Series; SVHC:No SVHC (12-Jan-2017); Actuation Type:Plunger; Actuator / Cap Colour:Black; Colour:Black; Contact Resistance:10mohm; Dielectric Strength VDC:1000V; External Depth:5mm; External Length / Height:15.75mm; External Width:8.1mm; Height Max:17.75mm; Insulation Resistance:1000Mohm; No. of Electrical Operations:100000; Operating Temperature Max:85°C; Operating Temperature Min:-20°C; Panel Cutout Diameter:4.25mm; Power Rating:400mVA

SWITCH DPDT; Switch Operation:On-(On); Contact Configuration:DPDT; Contact Voltage AC Nom:20V; Contact Voltage DC Nom:20V; Contact Current Max:-; Switch Terminals:Solder; Product Range:TP Series; SVHC:No SVHC (12-Jan-2017); ;RoHS Compliant: Yes
