Rear mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Tin plated solder area. Contacts included. RoHS Compliant: Yes

Rear mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Tin plated solder area. Contacts included. RoHS Compliant: Yes

Front mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. / 105 RoHS Compliant: Yes

Front mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. / 105 RoHS Compliant: Yes

SOCKET, FREE, 3WAY; Product Range:97 Series; Circular Connector Shell Style:Straight Plug; No. of Contacts:3Contacts; Circular Contact Type:Solder Socket; Coupling Style:Threaded; Insert Arrangement:10SL-3; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass, Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:General Duty; Equivalent Military Specification:MIL-DTL-5015 Series; SVHC:Cadmium (15-Jun-2015); Cable Diameter Max:1.4mm; Cable Diameter Min:0.8mm; Colour:Olive; Coupling Diameter:22.23mm; Current Rating:13A; IP / NEMA Rating:IP66; Length:34.93mm; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; Voltage Rating V DC:700V; Voltage Rating VAC:700V; Wire Size AWG Max:22AWG; Wire Size AWG Min:16AWG; Withstand Voltage:2000V; Working Voltage:700V

PLUG, PANEL, 6WAY; Product Range:97 Series; Circular Connector Shell Style:Box Mount Receptacle; No. of Contacts:6Contacts; Circular Contact Type:Solder Pin; Coupling Style:Threaded; Insert Arrangement:14S-6; Connector Body Material:Aluminium Alloy Body; Connector Body Plating:Olive Drab Chromate over Cadmium; Contact Material:Brass, Copper Alloy; Contact Plating:Silver; Insert Rotation:N; Service Class:General Duty; Equivalent Military Specification:MIL-DTL-5015 Series; SVHC:Cadmium (15-Jun-2015); Cable Diameter Max:1.4mm; Cable Diameter Min:0.8mm; Current Rating:13A; External Width:30.15mm; IP / NEMA Rating:IP66; Length:23.8mm; No. of Mating Cycles:500; Operating Temperature Max:125°C; Operating Temperature Min:-55°C; PCB Hole Diameter:3.25mm; Panel Cutout Diameter:23.83mm; Panel Cutout Size:23.01 mm; Voltage Rating V DC:250V; Voltage Rating VAC:250V; Wire Size AWG Max:22AWG; Wire Size AWG Min:16AWG; Withstand Voltage:1000V; Working Voltage:250V

CONNECTOR ROHS COMPLIANT: YES

Rear mounting male metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. NOTE: in order to avoid RoHS Compliant: Yes

CONNECTOR ROHS COMPLIANT: YES

Female cable connector with internal strain relief and metal locking ring. Complete EMI shielding in the fully mated and locked position (EMI security). Screw locking according to IEC 61076-2-106. Contacts sold separately. / 100 RoHS Compliant: Yes

Front mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts sold separately. / 100 RoHS Compliant: Yes

Front mounting male metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts sold separately. / 100 RoHS Compliant: Yes

Female cable connector with internal strain relief and metal locking ring. Complete EMI shielding in the fully mated and locked position (EMI security). Screw locking according to IEC 61076-2-106. Contacts included. NOTE: in order toRoHS Compliant: Yes

Female cable connector with internal strain relief and metal locking ring. Complete EMI shielding in the fully mated and locked position (EMI security). Screw locking according to IEC 61076-2-106. Contacts included. / 100 RoHS Compliant: Yes

Female cable connector with internal strain relief and metal locking ring. Complete EMI shielding in the fully mated and locked position (EMI security). Screw locking according to IEC 61076-2-106. Contacts included. / 100 RoHS Compliant: Yes

Rear mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. / 105 RoHS Compliant: Yes

Male cable connector with internal strain relief and metal locking ring. Complete EMI shielding in the fully mated and locked position (EMI security). Screw locking according to IEC 61076-2-106. Contacts included. NOTE: in order to RoHS Compliant: Yes

Male cable connector with internal strain relief and metal locking ring. Complete EMI shielding in the fully mated and locked position (EMI security). Screw locking according to IEC 61076-2-106. Contacts included. / 100 RoHS Compliant: Yes

Flange mount female metal receptacle with O-ring seal and ring nut (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Contacts included. NOTE: in order to avoid brittle RoHS Compliant: Yes

Rear mounting female metal receptacle with O-ring seal and ring nut mount (hex nut available upon request). Complete EMI shielding in the fully mated and locked position (EMI security). Tin plated solder area. Contacts included. RoHS Compliant: Yes
