PLUG FREE 3WAY; Product Range:C091B Series; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:3Contacts; Circular Contact Type:Solder Pin; Coupling Style:-; Connector Body Material:Metal Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Pin; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:5A; Dielectric Strength VAC:980V; Gender:Plug; IP / NEMA Rating:IP40; Insulation Resistance:1012Mohm; No. of Mating Cycles:500; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Test Voltage Contact / Contact:980V; Wire Area Size:0.5mm²; Working Voltage:250V

CIRCULAR CONNECTOR RECEPTACLE 3 POSITION PANEL; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Panel Mount Receptacle; No. of Contacts:4Contacts; Circular Contact Type:Screw Socket; Coupling Style:Threaded ;RoHS Compliant: Yes

SOCKET FREE SOLDER 6P+E WAY; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Cable Mount Receptacle; No. of Contacts:6Contacts; Circular Contact Type:Solder Socket; Coupling Style:-; Connector Body Material:Nylon (Polyamide) Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA GERMANISCHER LLOYDS SEV UL VDE; Approval Category:DIN EN 60664-1 DIN EN 60512-3-2 DIN EN 60512-3-1 DIN EN 60529; Cable Diameter Max:12.5mm; Cable Diameter Min:6mm; Colour:Blue / Black; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:10A; De-mating Force:30N; Degree of Pollution:3; Flammability Rating:UL94V-0; Gender:Receptacle; Housing:Polyamide 6.6/PA6; IP / NEMA Rating:IP67; Insulation Resistance:10Mohm; Insulation Resistance Voltage:250V

SOCKET FREE SOLDER AU 6P+E WAY; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Cable Mount Receptacle; No. of Contacts:6Contacts; Circular Contact Type:Solder Socket; Coupling Style:-; Connector Body Material:Nylon (Polyamide) Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Gold; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA GERMANISCHER LLOYDS SEV UL VDE; Approval Category:DIN EN 60664-1 DIN EN 60512-3-2 DIN EN 60512-3-1 DIN EN 60529; Cable Diameter Max:12.5mm; Cable Diameter Min:6mm; Colour:Blue / Black; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:10A; De-mating Force:30N; Degree of Pollution:3; Flammability Rating:UL94V-0; Gender:Receptacle; Housing:Polyamide 6.6/PA6; IP / NEMA Rating:IP67; Insulation Resistance:10Mohm; Insulation Resistance Voltage:250V

Circular Connector Ecomate C016 Series Receptacle 7 Socket Solder Cable Mount ;RoHS Compliant: Yes

Circular Connector Ecomate C016 Series Receptacle 6 Socket Crimp Cable Mount ;RoHS Compliant: Yes

Circular Connector Ecomate C016 Series Receptacle 7 Socket Cable Mount ;RoHS Compliant: Yes

CIRCULAR RECEPTACLE 6+PE WAY PANEL; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Flange Mount Receptacle; No. of Contacts:6Contacts; Circular Contact Type:Solder Socket; Coupling Style:-; Connector Body Material:Nylon (Polyamide) Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA VDE; Colour:Black; Connector Mounting:Panel Mount; Connector Type:Circular; Contact Gender:Socket; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:10A; De-mating Force:30N; Degree of Pollution:3; Fixing Centres:31mm; Flammability Rating:UL94V-0; Gender:Receptacle; IP / NEMA Rating:IP67; Insulation Resistance:10Mohm; No. of Mating Cycles:500; Operating Temperature Max:+125°C; Operating Temperature Min:-40°C; Wire Area Size Max:0.75mm²; Withstand Voltage:4000V; Working Voltage:250V

SOCKET PANEL SOLDER AU 6P+E WAY; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Flange Mount Receptacle; No. of Contacts:7Contacts; Circular Contact Type:Solder Socket; Connector Body Material:Nylon (Polyamide) Body; Contact Material:-; Contact Plating:Gold; SVHC:No SVHC (12-Jan-2017); Approval Bodies:CSA GERMANISCHER LLOYDS SEV UL VDE; Approval Category:DIN EN 60664-1 DIN EN 60512-3-2 DIN EN 60512-3-1 DIN EN 60529; Cable Diameter Max:12.5mm; Cable Diameter Min:6mm; Colour:Black; Connector Mounting:Panel Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Gold Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:10A; De-mating Force:30N; Degree of Pollution:3; Fixing Centres:31mm; Flammability Rating:UL94V-0; Gender:Receptacle; Housing:Polyamide 6.6/PA6; IP / NEMA Rating:IP67; Insulation Resistance:10Mohm; Insulation Resistance Voltage:250V; Mating Force:15N

CIRCULAR CONNECTOR PLUG 4 POSITION CABLE; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:4Contacts; Circular Contact Type:Screw Pin; Coupling Style:Threaded; Contact Material:- ;RoHS Compliant: Yes

Circular Connector Ecomate C016 Series Plug 3 Pin Screw Cable Mount ;RoHS Compliant: Yes

Circular Connector Ecomate C016 Series Receptacle 3 Pin Screw Panel Mount ;RoHS Compliant: Yes

Circular Connector Ecomate C016 Series Receptacle 3 Socket Screw Panel Mount ;RoHS Compliant: Yes

SOCKET PANEL 3WAY; Product Range:C091B Series; Circular Connector Shell Style:Panel Mount Receptacle; No. of Contacts:3Contacts; Circular Contact Type:Solder Socket; Coupling Style:-; Connector Body Material:Metal Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Connector Mounting:Panel Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:5A; Dielectric Strength VAC:980V; Gender:Receptacle; IP / NEMA Rating:IP40; Insulation Resistance:1012Mohm; No. of Mating Cycles:500; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Test Voltage Contact / Contact:980V; Voltage Rating VAC:250V; Wire Area Size:0.5mm²; Working Voltage:250V

SOCKET FREE R/A 6WAY; Product Range:C091D Series; Circular Connector Shell Style:Cable Mount Receptacle; No. of Contacts:6Contacts; Circular Contact Type:Solder Socket; Coupling Style:-; Connector Body Material:Metal Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Approval Bodies:UL; Approval Category:IEC 60664-1 UL 1977; Body Plating:Nickel; Cable Diameter Max:6mm; Cable Diameter Min:4mm; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Solder; Contact Termination Type:Solder; Current Rating:5A; Degree of Pollution:1; Flammability Rating:UL94V-0; Gender:Receptacle; IP / NEMA Rating:IP67; Insulation Resistance:1000Mohm; No. of Mating Cycles:500; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Voltage Rating VAC:300V; Wire Area Size:0.5mm²; Withstand Voltage:1500V; Working Voltage:300V

PLUG FREE 7WAY CRIMP; Product Range:C091D Series; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:7Contacts; Circular Contact Type:Crimp Pin; Coupling Style:-; Connector Body Material:Metal Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Approval Bodies:UL; Approval Category:IEC 60664-1 UL 1977; Body Plating:Nickel; Cable Diameter Max:6mm; Cable Diameter Min:4mm; Connector Mounting:Cable Mount; Connector Type:Circular Industrial; Contact Gender:Pin; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Crimp; Contact Termination Type:Crimp; Current Rating:5A; Degree of Pollution:1; Flammability Rating:UL94V-0; Gender:Plug; IP / NEMA Rating:IP67; Insulation Resistance:1000Mohm; No. of Mating Cycles:500; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Voltage Rating VAC:100V; Wire Area Size:0.5mm²; Withstand Voltage:1200V; Working Voltage:300V

SOCKET PANEL 7WAY CRIMP; Product Range:C091D Series; Circular Connector Shell Style:Panel Mount Receptacle; No. of Contacts:7Contacts; Circular Contact Type:Crimp Socket; Coupling Style:-; Connector Body Material:Metal Body; Connector Body Plating:-; Contact Material:-; Contact Plating:Silver; SVHC:No SVHC (12-Jan-2017); Approval Bodies:UL; Approval Category:IEC 60664-1 UL 1977; Body Plating:Nickel; Connector Mounting:Panel Mount; Connector Type:Circular Industrial; Contact Gender:Socket; Contact Plating:Silver Plated Contacts; Contact Resistance:5mohm; Contact Termination:Crimp; Contact Termination Type:Crimp; Current Rating:5A; Degree of Pollution:1; Flammability Rating:UL94V-0; Gender:Receptacle; IP / NEMA Rating:IP67; Insulation Resistance:1000Mohm; No. of Mating Cycles:500; Operating Temperature Max:85°C; Operating Temperature Min:-40°C; Voltage Rating VAC:100V; Wire Area Size:0.5mm²; Withstand Voltage:1200V; Working Voltage:100V

PLUG FREE 14+PE WAY; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Cable Mount Plug; No. of Contacts:15Contacts; Circular Contact Type:-; Coupling Style:-; Connector Body Material:Nylon 6.6 (Polyamide 6.6) Body; Connector Body Plating:-; Contact Material:-; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Connector Mounting:Cable Mount; Connector Shell Size:1; Connector Type:Circular Industrial; Contact Gender:Pin; Current Rating:12A; Current per Signal Contact Max:8A; Gender:Plug; IP / NEMA Rating:IP65; No. of Mating Cycles:500; No. of Positions:15Ways; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:Size 1; Voltage Rating VAC:100V; Wire Area Size Power Contact Max:1.5mm²; Wire Area Size Power Contact Min:0.5mm²; Working Voltage:400V

SOCKET FREE 14+PE WAY; Product Range:Ecomate C016 Series; Circular Connector Shell Style:Cable Mount Receptacle; No. of Contacts:15Contacts; Circular Contact Type:-; Coupling Style:-; Connector Body Material:Nylon 6.6 (Polyamide 6.6) Body; Connector Body Plating:-; Contact Material:-; Contact Plating:-; SVHC:No SVHC (12-Jan-2017); Connector Mounting:Cable Mount; Connector Shell Size:1; Connector Type:Circular Industrial; Contact Gender:Socket; Current Rating:12A; Current per Signal Contact Max:8A; Gender:Receptacle; IP / NEMA Rating:IP65; No. of Mating Cycles:500; No. of Positions:15Ways; Operating Temperature Max:125°C; Operating Temperature Min:-40°C; Range:Size 1; Voltage Rating VAC:100V; Wire Area Size Power Contact Max:1.5mm²; Wire Area Size Power Contact Min:0.5mm²; Working Voltage:400V

Circular Connector C16-3 Series Receptacle 18 Socket Crimp Panel Mount ;RoHS Compliant: Yes
