Altech Porcelain Cartridge Fuse, 10A, Speed T, 8 x 32mm. Voltage Rating: 380V ac. Diameter: 8.5mm. Overall Length: 31.5mm. Application Category: gL. MPN: 10C8X32GI

Altech 2A 1P Pole Thermal Magnetic Circuit Breaker, 240V ac L. Circuit Breaker Type: Miniature Molded Case. Reset Actuator Type: Toggle Switch. Overall Dimensions: 17.5 x 109 x 66.5mm. Overall Depth: 66.5mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type C. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 17.5mm. Application: Control Circuit, Lighting, Low Inrush Motors, Receptacles, Resistive Loads, Wiring Protection. Special Features: Medium Magnetic Trip Point, Relatively Short Thermal Trip Delay. MPN: 1CU2L

Altech 500mA 1P Pole Thermal Magnetic Circuit Breaker, 42 V dc, 277 V ac V-EA. Rated AC Voltage: 277V. Rated DC Voltage: 42V. Circuit Breaker Type: MCB. Reset Actuator Type: Toggle Switch. Overall Dimensions: 17.5 x 89.3 x 74.4mm. Overall Depth: 74.4mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type D. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 17.5mm. Application: Heaters, High Inrush Motors, Power Supplies, Reactive Loads, Transformers. Special Features: Relatively Long Thermal Trip Delay, Very High Magnetic Trip Point. MPN: 1D05UM

Altech 25A 2 Pole Thermal Magnetic Circuit Breaker, 480Y/277V R. Overall Length: 96.1mm. Application: Appliance Circuit, Control Transformers, Power Supplies, Power Supplies and Reactive Loads, Sensitive Electronics, UL1077 Application. Mounting Style: DIN Rail Mount. Overall Dimensions: 96.1 x 35 x 83.5mm. Terminal Contact Type: Screw. Break Time: Time Delay. Special Features: IP20 Termination Protection, Positive Trip Indicator, Supplementary Protector. Circuit Breaker Type: MCCB. Breaking Capacity at Maximum Voltage Rating: 10 kA. Tripping Characteristics: Type D. MPN: 2DU25R

Altech 300mA 2 Pole Thermal Magnetic Circuit Breaker V-EA. Rated DC Voltage: 80V. Circuit Breaker Type: MCCB. Reset Actuator Type: Handle. Overall Dimensions: 93.3 x 35 x 74.7mm. Overall Depth: 74.7mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type E. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 93.3mm. Application: AC Discharge Lamps (Ballast), AC General Use, AC Incandescent Lamps (Tungsten), AC Motor Starting, AC Resistance, Across the Line, High Efficiency Motors, UL508 Application, Which have Exceedingly High Inrush Current. Mounting Style: DIN Rail Mount. Special Features: IP20 Terminal Protection. MPN: 2E03UM

Altech 12.5A 2 Pole Thermal Magnetic Circuit Breaker, 480Y/277V V-EA. Circuit Breaker Type: MCCB. Reset Actuator Type: Handle. Overall Dimensions: 93.3 x 35 x 74.7mm. Overall Depth: 74.7mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type E. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 93.3mm. Application: AC Discharge Lamps (Ballast), AC General Use, AC Incandescent Lamps (Tungsten), AC Motor Starting, AC Resistance, Across the Line, High Efficiency Motors, UL508 Application, Which have Exceedingly High Inrush Current. Special Features: IP20 Terminal Protection. MPN: 2E125UM

Altech Cartridge Fuse, 100A, Speed T, 22.2 x 58mm. Voltage Rating: 500V ac. Diameter: 22mm. Application Category: gL. MPN: 100C22X58GI

Altech 25A 1 Pole Thermal Magnetic Circuit Breaker, 240V ac L. Circuit Breaker Type: MCCB. Reset Actuator Type: Handle. Overall Dimensions: 109 x 17.5 x 66.5mm. Overall Depth: 66.5mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type D. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 109mm. Application: Heaters and Reactive Loads, High Inrush Motors, Power Supplies, Transformer, UL489 Applications. Special Features: HACR Type, IP20 Terminal Protection, Line/Load Reversible, Positive Trip Indicator. MPN: 1DU25L

Altech 6A 1 Pole Thermal Magnetic Circuit Breaker, 42V dc V-EA. Circuit Breaker Type: MCCB. Reset Actuator Type: Toggle Switch. Overall Dimensions: 93.3 x 17.5 x 74.7mm. Overall Depth: 74.7mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type E. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 93.3mm. Application: AC Discharge Lamps (Ballast), AC General Use, AC Incandescent Lamps (Tungsten), AC Motor Starting, AC Resistance, Across the Line, High Efficiency Motors, UL508 Application, Which have Exceedingly High Inrush Current. Special Features: IP20 Terminal Protection. MPN: 1E6UM

Altech 10A 1 Pole Thermal Magnetic Circuit Breaker R. Overall Dimensions: 96.1 x 17.5 x 83.5mm. Overall Depth: 83.5mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type D. Mounting Style: DIN Rail Mount. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 96.1mm. Application: Appliance Circuit, Control Transformers, Power Supplies, Power Supplies and Reactive Loads, Sensitive Electronics, UL1077 Application. Terminal Contact Type: Screw. Reset Actuator Type: Handle. Break Time: Time Delay. Special Features: IP20 Termination Protection, Positive Trip Indicator, Supplementary Protector. MPN: 1DU10R

Altech 300mA 1 Pole Thermal Magnetic Circuit Breaker, 42V dc V-EA. Reset Actuator Type: Toggle Switch. Overall Dimensions: 93.3 x 17.5 x 74.7mm. Overall Depth: 74.7mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type G. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 93.3mm. Mounting Style: DIN Rail Mount. Circuit Breaker Type: MCCB. Terminal Contact Type: Box Clamp, Ring Tongue Terminal. MPN: 1G03UM

Altech 15A 1 Pole Thermal Magnetic Circuit Breaker, 42V dc V-EA. Circuit Breaker Type: MCCB. Reset Actuator Type: Toggle Switch. Overall Dimensions: 93.3 x 17.5 x 74.7mm. Overall Depth: 74.7mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type Z. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 93.3mm. Application: AC Discharge Lamps (Ballast), AC General Use, AC Incandescent Lamps (Tungsten), AC Motor Starting, AC Resistance, Across the Line, Components which Fail-Short, Components/Devices with Low Surge Current and Short Circuit Withstand Capabilities, Semiconductors, UL508 Application. Special Features: IP20 Terminal Protection. MPN: 1Z15UM

Altech 25A 1P Pole Thermal Magnetic Circuit Breaker, 48 V dc, 277 V ac R. Terminal Contact Type: Screw. Break Time: Time Delayed. Special Features: Positive Trip Indicator, Relatively Long Thermal Trip Delay But Low Magnetic Trip Point. Rated AC Voltage: 277V. Rated DC Voltage: 48V. Circuit Breaker Type: MCB. Tripping Characteristics: Type B. Reset Actuator Type: Toggle Switch. Overall Dimensions: 17.5 x 96.1 x 83.5mm. Overall Depth: 83.5mm. Breaking Capacity at Maximum Voltage Rating: 10 kA. Mounting Style: DIN Rail Mount. MPN: 1BU25R

Altech 8A 1P Pole Thermal Magnetic Circuit Breaker, 48 V dc, 277 V ac R. Rated AC Voltage: 277V. Rated DC Voltage: 48V. Circuit Breaker Type: MCB. Reset Actuator Type: Toggle Switch. Overall Dimensions: 17.5 x 96.1 x 83.5mm. Overall Depth: 83.5mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type B. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 17.5mm. Application: Appliances, Business Equipment, Control Circuit, Lighting, Power Supplies, Sensitive Electronics, Wiring Protection. Special Features: Positive Trip Indicator, Relatively Long Thermal Trip Delay But Low Magnetic Trip Point. MPN: 1BU8R

Altech 50A 1P Pole Thermal Magnetic Circuit Breaker, 240V ac UL. Break Time: Time Delayed. Special Features: Medium Magnetic Trip Point, Relatively Short Thermal Trip Delay. Circuit Breaker Type: MCB. Reset Actuator Type: Toggle Switch. Overall Dimensions: 17.5 x 105.3 x 74.4mm. Overall Depth: 74.4mm. Tripping Characteristics: Type C. Terminal Contact Type: Screw. Breaking Capacity at Maximum Voltage Rating: 10 kA. MPN: 1C50UL

Altech 63A 1P Pole Thermal Magnetic Circuit Breaker, 48 V dc, 277 V ac R. Rated AC Voltage: 277V. Rated DC Voltage: 48V. Circuit Breaker Type: MCB. Reset Actuator Type: Toggle Switch. Overall Dimensions: 17.5 x 96.1 x 83.5mm. Overall Depth: 83.5mm. Tripping Mechanism: Thermal-Magnetic. Tripping Characteristics: Type C. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 17.5mm. Application: Appliances, Business Equipment, Control Circuit, Lighting, Power Supplies, Sensitive Electronics, Wiring Protection. Special Features: Medium Magnetic Trip Point, Positive Trip Indicator, Relatively Long Thermal Trip Delay. MPN: 1CU63R

Altech Porcelain Cartridge Fuse, 25A, Speed T, 10 x 38mm. Voltage Rating: 500V ac. Diameter: 10.3mm. Application Category: gL. MPN: 25C10X38GI

Altech 30A 2 Pole Thermal Magnetic Circuit Breaker, 480Y/277V R. Overall Dimensions: 96.1 x 35 x 83.5mm. Overall Depth: 83.5mm. Tripping Mechanism: Thermal-Magnetic. Terminal Contact Type: Screw. Breaking Capacity at Maximum Voltage Rating: 10 kA. Overall Length: 96.1mm. Application: Appliance Circuit, Control Transformers, Power Supplies, Power Supplies and Reactive Loads, Sensitive Electronics, UL1077 Application. Mounting Style: DIN Rail Mount. Break Time: Time Delay. Reset Actuator Type: Handle. Circuit Breaker Type: MCCB. MPN: 2DU30R

Altech 60A 1P Pole Thermal Magnetic Circuit Breaker, 48 V dc, 277 V ac R. Overall Length: 17.5mm. Overall Depth: 83.5mm. Application: Appliances, Business Equipment, Control Circuit, Lighting, Power Supplies, Sensitive Electronics, Wiring Protection. Mounting Style: DIN Rail Mount. Terminal Contact Type: Screw. Break Time: Time Delayed. Special Features: Medium Magnetic Trip Point, Positive Trip Indicator, Relatively Long Thermal Trip Delay. Rated AC Voltage: 277V. Rated DC Voltage: 48V. Circuit Breaker Type: MCB. Reset Actuator Type: Toggle Switch. Breaking Capacity at Maximum Voltage Rating: 10 kA. MPN: 1CU60R

Altech 25A Bottle Fuse, 500V ac. Gauge/Cap Colour: Yellow. Body Material: Glass. MPN: 25D16FB
